Brand: Jet
Model : 354165
List Price : $463.00
Sale Price : $399.99
Availibility : Usually ships in 24 hours
|
JET 354165 JDP-15M 3/4-HP 15-Inch Bench Drill Press Feature
- Bench mount drill press with 16 speeds ranging from 200 to 3,630 RPM
- Crank-operated, rotating worktable tilts up to 45-Degree; full 10-by-13-Inch work surface
- 3/4 HP 115/230-Volt motor; 15-Inch swing; adjustable tension spindle return spring
- Includes 5/8-Inch drill chuck and key; built-in work-light (bulb not included)
- Measures 31-by-13-by-39-1/2-Inch (Length by Weight by Height); weighs 150-Pound
JET 354165 JDP-15M 3/4-HP 15-Inch Bench Drill Press Overviews
This JET 15in. Drill Press is ideal when limited space is a concern. The versatile JDP-15M cuts perfectly perpendicular holes, and 16 speeds allow you to use it for non-drilling chores such as sanding, mortising, shaping, routing, plating, and other practical jobs. Reconfiguration is easy, with a hinged metal belt and pulley cover gives you easy access to the quick-adjustment motor mount for rapid spindle speed changes. The rotating 45deg operated worktable has a quick-release clamp for fast, accurate adjustments for more efficiency and creativity. HP: 3/4, Volts: 115/230, Speed (RPM): 200 – 3,630, Speeds (qty.): 16, Swing: 15 Inches, Drilling Capacity (in.): 5/8, Chuck Size (in.): 5/8, Worktable L x W (in.): 16 1/2 x 13, Light Included: No, Stand Included: No, Dimensions L x W x H (in.): 39 1/2 x 13 x 31
JET 354165 JDP-15M 3/4-HP 15-Inch Bench Drill Press Specifications
Incredibly versatile and easy to use, the JET 354165 JDP-15M 3/4 HP 15-Inch Bench Drill Press offers 16 speeds (200 to 3,630 RPM) so you can choose the best speed for the job. Ideal for home shop use, this efficient press has a 15-inch swing, comes with a 5/8-inch drill chuck and key, and includes a convenient built-in work light (bulb not included).
 |
The JET JDP-15M 15-Inch Bench Drill Press offers:
- A 3/4 HP 115/230-volt motor for reliable power
- 16 speeds (200 to 3,630 RPM) for job-specific performance
- Quick-release, crank-operated worktable height adjustment
- An easy-access push-button switch for convenient operation
- A 10-by-13-inch work surface in front of the drill bit
|
 |
|
A 3/4 HP motor delivers efficcient and reliable drilling performance. View larger. |
A large work surface with mounting grooves and crank-operated height adjustment provides versatility. |
Large Work Table and X-Pattern Grooves for Flexibility
The JDP-15M tackles jobs both big and small, thanks to its quick-release, crank-operated worktable height adjustment, which allows rotation to 45 degrees in either direction. It also features a full 10-by-13-inch work surface in front of the drill bit. For added flexibility, the table features X-pattern mounting grooves, and it is reversible for mounting a fence in the rear mounting grooves.
Powerful Motor and Adjustable Tension Spindle Return for Consistency
The JDP-15M owes its robust performance to a 3/4 HP, 115/230-volt motor for reliable power and variable speed. It also has a 15-inch swing and includes an adjustable tension spindle return that’s ideal for repetitive drilling of the same depth.
Time-Saving Hinged Metal Belt, Pulley Cover, and Quick-Set Bolt
A hinged metal belt and pulley cover provide quick and easy access to the quick adjustment motor mount, making for rapid spindle speed changes. To save you even more time, the depth stop displays in both inches and millimeters, and it has a quick-set bolt for fast, accurate adjustments.
Push-Button Switch and Ball bearing Construction for Safety and Durability
Designed to be both durable and user-friendly, the JDP-15M features a push-button switch conveniently located on the front, and the spindle is supported by high-quality ball bearings. Finally, the 66-millimeter quill assembly can fit the optional Jet mortising attachment–perfect for those looking to expand the capabilities of the drill press.
The JDP-15M measures 23 x 12 x 32 inches (WxHxL), weights 163 pounds, and comes with a five-year warranty.
About JET: A History of Sharing New, Feature-Rich Products
Opened in 1958 after the founder of the company, Leslie P. Sussman, took the first Boeing Jet Airplane trip from Seattle, Washington to Japan, JET began as a small dealer that sold air hoists and trolleys out of a single hardware store in Seattle. Over the years, JET has carried everything from snowmobiles, transmitter radios, and forklifts to nylon stockings, but by the early 1970s, metalworking had become the base of their business line. And by the 1980s, JET had expanded into the realm of woodworking. Today, you’ll find that JET offers a wide range of popular woodworking tools that are backed with best-in-class features and excellent service.
What’s in the Box
Bench mount drill press, 5/8-inch drill chuck, and key.
