Brand: Jet
Model : 708457DXK
List Price : $979.00
Sale Price : $849.99
Availibility : Usually ships in 1-2 business days
|
JET 708457DXK JJ-6CSDX 6-Inch 1 HP Jointer with Quick-Set Knive System, 115/230-Volt 1-Phase Feature
- Extra-Long cast iron table for better control and more accuracy
- 1/2-Inch Rabbeting Capacity; 33-1/8-Inch long fence with 45 and 90-Degree stops
- Powerful 1-horsepower motor;-industrial push button controls
- 3 high-speed steel knives-Inch the cutter head; Quick Set Knives provide easy changing
- 4-Inch dust port for efficient dust and chip disposal
JET 708457DXK JJ-6CSDX 6-Inch 1 HP Jointer with Quick-Set Knive System, 115/230-Volt 1-Phase Overviews
The JET 6in. Long Bed Jointer offers one of the longest working surfaces in its class. Three high speed steel quick-change knives provide rapid cutting and a superior finish without the need for a knife-setting gauge. An exclusive auto-set quick-change knife system lets you replace or change all three blades in a fraction of the time other machines take. A powerful 1 HP motor easily handles the toughest jointing tasks. Cutting Width (in.): 6 1/6, Cutting Depth (in.): 1/2, Cuts Per Minute (CPM): 6,000, Amps: 13, Tool Length (in.): 56, Case Included: No
JET 708457DXK JJ-6CSDX 6-Inch 1 HP Jointer with Quick-Set Knive System, 115/230-Volt 1-Phase Specifications
Ideal for home shop use, the JET 708457DXK JJ-6CSDX 6-Inch 1 HP Jointer with Quick-Set Knive System squares your wood without fail. Offering one of the longest working surfaces in its class, and featuring an exclusive auto-set quick change knife system that lets you quickly replace or change all three blades, this powerful jointer helps you build doors, tabletops, and other furniture pieces with ease.
 |
The JET JJ-6CSDX
6-Inch Jointer offers:
- A powerful 1 HP motor for tough jointing tasks
- Three high-speed steel quick change knives for rapid cutting and a superior finish
- Extra-long heavy-duty cast iron infeed and outfeed tables
- A built-in dust chute with four-inch port
|
 |
|
Up-front controls help you maintain accuracy. |
The exclusive auto-set quick change knife system lets you replace or change all three blades quickly and easily for improved workflow. View larger. |
The JJ-6CSDX is a convenient, dependable, and versatile jointer. View full diagram. |
Center fence controls allow quick adjustments. |
All-Enclosed Steel Base Cabinet for Stability
The JJ-6CSDX comes with an all-steel enclosed base cabinet. An integral tab at each end of the cabinet bottom makes it easy to secure the jointer to the floor whenever a suitable surface is available. This cabinet also provides a stable platform and puts the table surface at a comfortable 31-1/4 inches above the floor.
Fan-Cooled Motor for Consistent Performance
The base cabinet also houses the 1 HP, 1 phase 115/230-volt TEFC (totally enclosed fan cooled) motor (pre-wired 115-volt) and wiring to help isolate those components from the dust-prone jointer environment. A large door on the rear of the base cabinet provides easy access to the motor, which spins the JJ-6CSDX cutterheads at a very consistent 6000 RPM for a desirable balance between speedy material removal and a silky-smooth surface on the wood.
Long Cast-Iron Table for Better Accuracy
The JET JJ-6CSDX features a long, cast-iron table with a smooth, flat precision-machined finish that keeps the wood sliding predictably while ensuring accuracy. Measuring 55-3/4 x 7-3/8 inches, this table makes straightening large project pieces accurate and reliable. Additionally, the overall cut capacity of 6-1/16 x 1/2 inches (WxD) can keep up with even the most active of home wood shops. Finally, the outfeed tables have built-in 1/2-inch rabbeting ledges that add a little more versatility to the jointer.
Handwheels for Easy Adjustments; Automatic Limiter for Safety
Both the infeed and outfeed tables feature Jet’s exclusive front-mounted handwheels to make table height adjustments easy and accurate. And for safety and protection, an automatic limiter on the infeed table prevents the operator from accidentally taking overly aggressive cuts deeper than 1/8 inch. For added convenience, the depth limiter can be manually overridden easily but requires the operator to intentionally release it.
Steel Cutterhead with Three Knives for Long Life
The JJ-6CSDX uses a precision-machined steel cutterhead fitted with three high-quality knives measuring 6 1/6 x 3/4 x 5/64 inches (WxLxD). These knives have two cutting edges that effectively double their life, and they are aligned using Jet’s exclusive auto quick-set system. A pair of cams at each knife actually adjusts the knife height. Once set, the cams are locked in position and the knives can be reversed or replaced without having to reset the height, eliminating the need for a knife-setting gauge.
Additionally, precision-machined pockets in the knives let you slip them onto the cams, thus retaining the setting. The openings in the knives are also wide enough that individual knives can be offset to compensate for a nick, further extending the life of each knife edge.
User-Friendly Features for Easy, Pleasant Operation
Designed to be an easy-to-operate, helpful addition to your shop, the JJ-6CSDX features a two-way tilting fence with positive stops at 45 and 90 degrees to handle bevel operations, as well as industrial push-button controls conveniently placed for easy access. Finally, a built-in dust chute with four-inch port connects to your collection system for efficient dust and chip disposal.
The JJ-6CSDX measures 22 x 37.5 x 56 inches (WxHxD), weighs 237 pounds, and is backed by a five-year warranty.
About JET: A History of Sharing New, Feature-Rich Products
Opened in 1958 after the founder of the company, Leslie P. Sussman, took the first Boeing Jet Airplane trip from Seattle, Washington to Japan, JET began as a small dealer that sold air hoists and trolleys out of a single hardware store in Seattle. Over the years, JET has carried everything from snowmobiles, transmitter radios, and forklifts to nylon stockings, but by the early 1970s, metalworking had become the base of their business line. And by the 1980s, JET had expanded into the realm of woodworking. Today, you’ll find that JET offers a wide range of popular woodworking tools that are backed with best-in-class features and excellent service.
What’s in the Box
One stand with motor, one stand cover with mounting hardware, one dust chute with mounting hardware, one bed assembly, one fence assembly, one cutterhead guard, one belt guard, one V-belt, four 1/4-20 x 1/2 pan head screws, four 1/4 flat washers, one lock handle, flat washer and lock nut for the fence, one fence handle, three lock bolts, three 3/8-inch lock washers, two handwheel assemblies, one can of touch-up paint, manual, warranty card, and two push blocks.
